Timber, Digging & Crane Mats
Crane Mats, Timber Mats, and Digging Mats
When the job site requires the heaviest machinery like cranes, excavators, and tracked or untracked equipment to gain safe access across bridges/trusses, roads, wetland right of way, or temporary bridge abutments, then our heavy-duty crane, timber and digging mats are required.
Constructed from high quality hardwood and softwood beams, our toughest mats create a strong and reliable foundation for even the heaviest equipment and can be built to any size depending on your site’s specific needs.
Each mat is designed and constructed for optimal durability, easy transportation and since on-site operations rarely stay in one place, we’ve designed these heavy-duty mats with optional notched or cabled ends making adjustment on-site a simple task.
Crane, Timber & Digging Mat Specifications
From manufacturing to delivery and installation our full-service operations team will work with you to create a safe, stable base for your crews and equipment to work from.
Each mat is constructed to our stringent standards and runs through our quality assurance team to ensure the best product is delivered to your site.
Custom sizes available
- Optional notched or cabled ends
- Constructed with standard sawn 8”x8”, 10”x10” or 12”x12” timbers
- Built with premium #2 or better Douglas fir, hemlock, or hardwood lumber
- Heavy-duty countersunk bolts
- 1” rods, 1 1/4” rods available for extra reinforcement
- Constructed with 8″ x 8″ x 16″ Timbers
- 100% red and white oak or mixed hardwood (oak, cherry, hickory, elm, pecan)
- Bolts meet the grade of SAE Grade #2
- Bolts have a carriage bolt head on one end and nut and washer on opposite end
- Minimal stain and wane
